PART NO IS910E
900A PEAK AMPS, 240A CLAMP POWER
This powerful and compact lithium jumpstarter is capable of starting most petrol engines up to 6.0L*.
OVERVIEW
New ‘smart module‘ provides unparalleled safety
90% lighter than equivalent lead acid jump starter
Built in L.E.D flood light
Powerbank functionality
SPECIFICATIONS
PART NO
IS910E
APPLICATION
Emergency
OUTPUT
12V
NO. OF JUMPSTARTS
(Without a vehicle battery)
7 (Petrol) 0 (Diesel)
EMERGENCY JUMPSTARTS
(With a flat vehicle battery)
14 (Petrol) 0 (Diesel)
SUITABLE FOR VEHICLES
Up to 6.0L petrol
VEHICLE VOLTAGE RANGE
0 – 15.0V
USB OUTPUT
USB OUTPUT
2.1A, 5.0V
USB LOW VOLTAGE DISCONNECT
Battery voltage at 9.0V
BATTERY
BATTERY CAPACITY
6,600mAhr at 3.7V, 24.4wHr at 3.7V, 2.2Ahr at 12.0V
BATTERY CHEMISTRY
Lithium Cobalt (LiCo)
THEORETICAL SHORT CIRUIT CURRENT
900A
CLAMP OUTPUT
240A
TOTAL BATTERY CYCLES
500
JUMPSTARTER LEADS
LENGTH
Positive 23.5cm, negative 16.5cm
CABLE
8mm² 8(AWG)
POLARITY PROTECTION
MCU controlled with Electronic Switch Smart Module
RECHARGING
CABLE
1m long USB to Micro USB
MICRO USB CHARGING PORT
2.1Amp micro USB charging port. 3rd party 10W 240VAC USB adaptors can be used (not supplied)
12V DC CHARGING
12V to 5V 2.1Amp USB charger (provided)
RECHARGE TIME
4 hours
JUMPSTARTER
WEIGHT
0.61 kg
DIMENSIONS
H: 47mm L: 178mm W: 91mm
OPERATING TEMPERATURE
0 to 45°C
STORAGE TEMPERATURE
-20 to 40°C
INGRESS PROTECTION
IP52 (rain proof) with covers over the ports
FEATURES
ADDED PROTECTION, SAFETY AND RELIABILITY
Unparalleled safety with a simple to use connection protecting the user, vehicle and jumpstarter. The addition of the ‘Smart Module’ adds a second layer of protection, preventing the unit from over charging.
Engine top operation
The compact and lightweight IS910E is more than 90% lighter than the equivalent lead acid jumpstarter. This allows the unit to sit on the engine while in use
L.E.D indicators
Monitor the jumpstarter’s charge level and display jumpstart status from the easy to read LED indicators and battery status button
2.1A USB Accessory Port
In addition to being a jumpstarter the IS910E also acts as a power bank enabling charging of any phone type as well as tablets and other portable devices such as sat navs.
Flood light with SOS function
IS910E is equipped with 2 x 0.5W LED flood light with SOS function allowing safe and easy use at night.
*Starts most petrol vehicles up to 6.0L
